Development mode: Ability to log actions/mutations within Vue devtools

[b44rd]

What problem does this feature solve?

Referencing to vuejs/devtools-v6#179

A pretty sweet development feature would be to add another tab inside Vue devtools that track the flow of actions and mutations. The suggestion is to allow a function such as devtools.log inside both store.dispatch and store.commit that holds the passed params. I´ve been using a custom library to do this for a while (b44rd/jsbug), and it sure provides another level of debuggability. The problem though, is that I currently need to add a line of code inside each action/mutation to achieve this overview.

For instance, when dispatching an action, this might look like this inside a new tab inside Vue devtools:

▶ Action: [actionName] [timestamp]

When clicked, this can be expanded, such as

▼ Action: [actionName] [timestamp]
  {
    points: 1
  }

The result list then visible in Vue devtools might then look like this. Note: Making actions print in a different color than mutations makes it really easy to follow the flow

▶ Action: "init" 10:00:002
▶ Mutation: "INIT" 10:00:004
▶ Action: "jump" 10:01:026
▶ Mutation: "JUMP" 10:01:031
▼ Action: "collectPoint" 10:02:005
  {
    points: 1
  }
▼ Mutation: "SET_STATUS" 10:02:015
  {
    points: 1,
    status: 'hero'
  }

What does the proposed API look like?

I believe it can be an alternative to extend Vue.config to enable/disable this feature. Since Store.prototype.commit is already logging to the mutation panel, I believe Store.prototype.dispatch can also be modified to do the same, so we will basically be able to call something similar to these two when dispatching actions or committing mutations

devtools.logAction('actionName', payload)
devtools.logMutation('mutationName', payload)

[posva]

Isn't this achieved with https://vuex.vuejs.org/en/plugins.html#built-in-logger-plugin?

[b44rd]

@posva Thanks! Will have a look at this one. I´ve not studied the code enough to realize what´s fully happening in order for vue-devtools to pick this up. But isn´t this plugin mainly focusing on mutations? The overall idea of this feature request is to achieve a log that also tracks actions, so the action -> mutation flow somehow becomes debuggable inside a theoretical devtools panel.

[posva]

Actions are not logged because they don't affect the state, and mutations can happen asynchronously inside of actions

[b44rd]

Yes, your point is a valid one for sure. However, if actions also becomes a part of the same log, a list like this can easily be produced.

In this particular app, the actions are displayed in a light green color, while the mutations are defined in a darker green color. As seen in top of the screenshot, it doesn´t matter too much if the actions are asyncronous. You´re still able to debug what data was comitted from the action.

You´re right about the time travel though. It will not be possible to enable time travel using this feature, but the overall debugging becomes a lot easier. Knowing what´s passed to an action, and what the action dispatches will for sure make it easier to discover potential bugs.

[posva]

You´re still able to debug what data was comitted from the action.

So you want the possibility to associate mutations to the action they were emitted from? This would be possible with an action enhancer (a function returning the actual action)

BTW, nice log 😄, I'm sure I saw it somewhere else already

[b44rd]

Thanks! Yes, that log (jsbug) is for sure a really nice addition to vue devtools. 👍

That´s basically why I hoped it could be an alternative to automatically log everything related to actions and mutations in the same way inside a panel of vue devtools. The alternative to define a function that returns store.dispatch is also a nice approach, but having it as a part of the devtools would for sure simplify things.

The main reason I think it´s a good idea, is that when a mutation do not mutate the state as expected, I often find myself spending time debugging both the function dispatching the action, and also the actual action itself.

If actions and mutations are listed as in the screenshot, a diff of the expected outcome from action to mutation is very easy to figure out.

Your argument saying that actions are not compatible with time travel is also a valid argument. Because of the async nature, this will make the current vuex tab less usable.

If however adding an actions tab, actions can be inspected in the same way, and optionally along with mutations inside the same list, I believe this could be pretty sweet. Pardon for a very rapid sketch, btw. But I believe it illustrates the usefulness quite well.

Let me know your thoughts, and I´ll be happy to help with the implementation.

[posva]

To me, the whole point of Vuex in devtools is inspecting how the state changes, so having actions there doesn't bring anything. It could, however, be an extra information when selecting the mutation (appearing on the right)

Pardon for a very rapid sketch, btw. But I believe it illustrates the usefulness quite well.

Taking the time for sketching is already nice, imo 🙂

[b44rd]

Hey! That's perhaps the absolutely optimal solution indeed. 😀

The important thing is to somehow be able to inspect the params of the action, and compare those with the params of the mutation, and then be able to see the result of the chain.

I believe this will provide valuable information for a lot of developers, and at the same time save a lot of debugging time. 👌

Are the action name and params already available for the logger? Because then it can simply be provided as a mutation callee list item, that can be displayed directly after the mutation item?

[posva]

No, it doesn't exist yet, but you can create an action enhancer. The concept may not be clear yet as we haven't documented it but you can look it up at vuexfire

Having an action driven view in devtools can be useful but it should be another view different from mutations' one

[b44rd]

Agreed. Will have a look and try to understand action enhancers then! 👍

But then, how do you think the actions will be displayed in an optimal way? Adding it as a list item to the right column, under state - getters - mutation? As for example "action"..?

Then, the action can be shown approximately as within the sketch. Though, perhaps only with the labels "name" and "arguments/payload". This way, the payload of the mutation can be diffed/compared very fast and efficient against the arguments/payload of the action. What do you think?

[deini]

@b44rd Do you have any update on this? I'm really interested in this feature, let me know if I can help!

[b44rd]

Hi, @deini, haven't yet been able to investigate this further, but it's for sure on my todo-list. I believe making the gui inside vue-devtools will be a quite simple task though, so the first action point will be to be utilize the action enhancers, in order to pass the name and params of the action to some logging function.

From this stage, I really like the idea of adding another field to the right side Vuex pane. I believe a field named action, containing the callee action name, action timestamp and action params will do the job quite well. It will at least make it possible to debug which action caused the mutation, and if the parameters passed along to the action corresponds to the ones passed to the mutation. Plus you will no longer need to debug/log actions elsewhere.

If you'll be able to start before I do, please let me know which branch you're working on, and we can continue together.

[deini]

Thanks for the info @b44rd would love to work together on this.

I was looking at action enhancers and if I understand the concept correctly this will require the users to use a custom action, like import { firebaseAction } from 'vuexfire' and then use that to compose actions. Is that correct @posva?

Is that the only option we have? Not sure if that would be ideal since now the user will need to use this custom enhancer just to get the logs.

[posva]

Yeah, that would be the way and no, it's far from ideal 😅
This is something that few people find useful and is a dev only feature, so IMO having it as part of Vuex is not reasonable unless it gets completely stripped off in production builds
